Dayton Mill/Drill Machine, 60 Hz, 13.0A
Original price was: $545.00.$92.99Current price is: $92.99.
Mill Drill Machine, Phase 3, Swing 11 in
Dayton #467L69 Specifications
- Zoro #: G7125023
- Mfr #: 467L69
- Swing: 11 in
- Voltage: 460V
- RPM: 50 to 10,000
- Item: Mill Drill Machine
- Drilling Capacity Steel: 1 in
- Spindle Speed: 50 to 10,000 rpm
- Face Milling Capacity: 2 1/2 in
- Motor HP: 1.5
- Phase: 3
- Longitudinal Travel: 12 1/4 in
- Cross Travel: 7 7/8 in
- Chuck Size: Not Included
- Amps: 13.0
- End Milling Capacity: 1 1/4 in
- Spindle Taper: BT30
- Spindle: BT30
- Features: Siemens 808D Control System, Door Equipped with A Safety Switch, Central Lubrication, Cooling System, Double Line 24V Electric Hand Wheel
- Corded/Cordless: Corded
- Head: Belt Drive
- Operation: Power
- Table Surface Height: 37 in
- Spindle Travel: 11-3/4″
- Spindle to Table: 15-1/3″
- Graduations: 0.0010 in
- Includes: Cover
- T-Slots: 5/8″
- Motor Type: TEFC
- Table Work Surface: 8 in x 27 in
- Hz: 60
- Power Source: Corded
- T-Slot Width: 5/8 in
- Motor Horsepower: 1 1/2
- Frequency: 60Hz
- Speed: 50 to 10,000 rpm
- Country of Origin (subject to change): China
