Jet Lathe, 230 Volts, 2 HP, 1 Phase
Original price was: $481.00.$92.99Current price is: $92.99.
Lathe, Distance Between Centers 40 in, Voltage 230V AC, Horsepower 2 hp, Min. Spindle Speed 70 RPM, Application Wood Turning, Overall Height 71 in, Overall Length 75 in, Overall Width 32 in, Max. Spindle Speed 2,000 RPM, Tailstock Taper MT4, Spindle Nose Type D1-4 Camlock
Jet #321101AK Specifications
- Zoro #: G9866911
- Mfr #: 321101AK
- Item: Lathe
- Motor HP: 2
- Phase: Single
- Voltage: 230V AC
- Frequency: 60 Hz
- Swing Over Bed (In.): 13
- Horsepower: 2 hp
- Spindle Bore (In.): 1-3/8
- Number of Threads (mm): 27
- Spindle Taper: 5 MT (3MT)
- Bed Width (In.): 7-3/8
- Cross Feed Rates: 0.0012″ to 0.0345″
- Overall Width: 32 in
- Distance Between Centers (In.): 43
- Tailstock Taper: MT4
- Features: One of the Most Popular Jet Lathes Now Comes with an Enclosed Gear Box. Enclosed Gear Box Design Provides Smooth, Quiet Operation. Fast, Easy Speed Changes. Hardened and Ground Gears are Featured in the Headstock and Gearbox. D1-4 Spindle is Precision Ground for Accuracy and Supported by High Quality Tapered Roller Bearings. Headstock is Constantly Oiled During Operation. Gear Box Gives Wide Inch Threading and Feed Capabilities with No Gear Changes. V-Way Bed Design is Induction Hardened and Ground. Gap Bed Section Provided for Larger Diameter Work. Independent Leadscrew and Feed Rod.
- Hz: 60
- Compound Travel (In.): 2-11/16
- Swing Over Cross Slide (In.): 7-25/32
- Number of Threads (In.): 40
- Includes: Taper Attachment
- Swing In Gap (In.): 18-3/4
- Spindle Speed (RPM): 70 to 2000
- Cross Travel (In.): 6-5/16
- Thread Range (In.): 4 to 112
- Overall Length: 75 in
- Thread Range (mm): 0.2 to 6
- Tailstock Travel (In.): 3-3/4
- Number of Spindle Speeds: 8
- Gap Length (In.): 8
- Carriage Travel (In.): 35
- Coolant Tank Capacity: 3 gal
- Overall Height: 71 in
- Longitudinal Feed Rates: 0.0018 to 0.0374
- Max. Metric Thread: 10 mm
- Gap Length: 8 in
- Swing Over Bed: 13 in
- Max. Threads per Inch: 80
- Max. Spindle Speed: 2,000 RPM
- Distance Between Centers: 40 in
- Bed Width: 8 in
- Max. Cross Feed: 0.0130 in
- Spindle Nose Type: D1-4 Camlock
- Number of Inch Threads: 38
- Swing In Gap: 18 3/4 in
- Min. Metric Thread: 0.45 mm
- Min. Spindle Speed: 70 RPM
- Min. Cross Feed: 0.0006 in
- Spindle Bore: 1 3/8 in
- Min. Threads per Inch: 3 1/2
- Swing Over Cross Slide: 7 25/32
- Spindle Dia.: 1 1/4 in
- Number of Metric Threads: 23
- Application: Wood Turning
- Sound Level: 88 dB
- Country of Origin (subject to change): China
