Wilton Lathes, 230/460V Volts, 10 HP HP, 3 Phase
Original price was: $454.00.$92.99Current price is: $92.99.
Lathe, Distance Between Centers 80 In., Voltage 230/460V, Horsepower 10 HP, Min. Spindle Speed 25 RPM, Overall Length 160.00mm, Max. Spindle Speed 1800 RPM, Tailstock Taper 5 In.
Wilton #321579 Specifications
- Zoro #: G5222001
- Mfr #: 321579
- Item: Lathes
- Phase: Three
- Voltage: 230/460V AC
- Frequency: 60 Hz
- Horsepower: 7 1/2 hp
- Includes: (5) Piece Quick Change Tool Post Set, 10 in 3 Jaw Scroll Chuck with Top Reversing Jaws, 12 in Face Plate, Articulating LED Work Lamp, Centrally Located Controls with Jog Button, Electronic Chuck Key Holder, Fitted Top Mats to Hold Tooling, Follow Rest, Foot Brake, Full Length Splash Guard and Coolant Return, Fully Integrated Coolant System, Large Capacity Steady Rest with Ball Bearing Tips, Live Center, Mounting Pads and Levelers, Threading Dial, Tolerance Test Certificate, Tool Box and Adjusting tools.E-Stop on Carriage
- Features: End Mill Style, Inch and Metric, Spiral Cutting Edge, Steel and Carbide Tool Shanks, Very High Insert Diameter (+0 / -20micron m) and Corner Radius Precision ( +/-8micron m)
- Overall Width: 40 in
- Overall Height: 48 7/8 in
- Overall Length: 136 in
- Tailstock Taper: MT5
- Number of Spindle Speeds: 12
- Distance Between Centers: 80 in
- Gap Length: 12 in
- Max. Cross Feed: 0.0360 in
- Min. Metric Thread: 0.05 mm
- Swing Over Cross Slide: 13 in
- Number of Inch Threads: 61
- Min. Cross Feed: 0.0006 in
- Min. Spindle Speed: 25 RPM
- Max. Spindle Speed: 1,800 RPM
- Bed Width: 12 in
- Machine Type: Engine lathe
- Spindle Bore: 3 1/8 in
- Number of Metric Threads: 24
- Min. Threads per Inch: 1 5/8
- Max. Metric Thread: 20 mm
- Swing Over Bed: 22 in
- Max. Threads per Inch: 72
- Spindle Nose Type: D1-8 Camlock
- Sound Level: 88 dB
- Swing In Gap: 29 1/2 in
- Application: Turning
- Country of Origin (subject to change): China
